Before proceeding, carefully read the | |
DescriptionM2-M30 missing | SeverityLow01 / 05 |
Authorized personnelMachine operator | Required PPE:  |
Description
….
Symptoms
when using the TEST ISO function, the message " appearsPE0041 CH 0 Program without M2-M30" on any ISO file
The same ISO files can be executed normally
The problem is caused by the fnzm30.srt file on the customer's CNC.
Possible solutions
Download the attached fnzm30.srt file
Copy it to the C:\kvara\DiscoC\Iso folder on the customer's machine
Open KvIsoGui
Menu > Archive Management
In the left-hand pane, go to the C:\kvara\DiscoC\Iso folder
Click in the right-hand pane
Click "Change Drive" in the buttons at the bottom
Select the CNC C drive
Select the fnzm30.srt file in the C:\kvara\DiscoC\Iso folder in the left-hand pane
Click "Copy" in the buttons at the bottom
fnzm30.srt file below.
