Technical troubleshooting sheet Emergency diagnostic procedure

PE0069SUCTION CUPS NOT IN PARKING POSITION

Before proceeding, carefully read the

SAFETY INSTRUCTIONS

DescriptionSuction cups out of parking position

SeverityLow01 / 05

Authorized personnelMachine operator

Required PPE:


Description

This error appears when the machine detects that one or both suction cups are not in the parking position.

Symptoms

…..

Possible causes

  1. No air supply

  2. Suction cups lowered

  3. Sensors incorrectly adjusted

  4. Faulty sensors

Possible solutions

  1. If this occurs together with PE0066 Air missing, check that air is supplied to the machine

  2. Press the appropriate button to raise the suction cups

  3. Open the steel covers on the sides of the suction-cup arms and check that the sensors at the top of the cylinder are on when the suction cups are raised.

;
